â— The first ground stand HD monitor, designed specially for outdoor users,
does not have “blue screenâ€, is your best choice FPV or photography
◠High resolution 1024X600,contrast ratio 500:1 and brightness 450cd/ ㎡
(8″),seizing much more clear world
â— Multi color format support, enter the menu manually to select the same
format as your can.
â— Analog composite video AV input, connect the aerial camera
â— 16:9 aspect ratio, switch the display mode 16:9 and 4:3
â— Connect with the camera, as a monitor or secondary monitor of aerial
â— High brightness,contrast ratio&Dizzy-proof monitor with sun shade, to see
clearly under sunshine.
â— 1/4-20 thread hole is included in the bottom, easily to mount on the tripod.

Model: | FPV-101DT |
Brightness: | 450cd/m2 200cd/m2 |
Resolution: | 1024x600 Pixels 1366x768 Pixels |
Contrast: | 500:1 |
Aspect Ratio: | 16:9 |
Backlight: | LED |
Viewing Angle: | 70°/70°(L/R) 50°/70°(U/D) |
Surface Treatment: | Anti-Glare |
Support video format: | NTSC M, PAL M, NTSC BG, PAL N, NTSC DK, PAL DK, PAL I and SECAM BG. |
Speaker | Built in, 1 Watt |
Input | |
Inputs: | AV,HDMI |
Power | |
Power Consumption: | ≦8W |
Input Voltage: | DC 6V-24V |
Enrivonment | |
Install Way: | 1/4-20 Thread and VESA mounting socket(75mm) |
Working Temperature: | -20℃~50℃ |
Storage Temperature: | -20℃~60℃ |
Dimension | |
Unit Size: | 255(L)× 163(W)×34(H) mm |
Unit Weight: | 530g |
